Lion 10 10-Inch Heavy-Lift Long-Range FPV Drone Solution | 6kg Payload + 10km Range + 45min Endurance, Covering Inspection / Recon / Surveying / Logistics Industrial Scenarios
Solution Overview This solution is built around the Lion 10 10-inch heavy-lift long-range FPV drone as the core operational platform. Leveraging its 10-inch high-strength heavy-lift airframe, 6kg maximum / 4kg standard operating payload, 45-minute extended no-load…
Solution Overview
This solution is built around the Lion 10 10-inch heavy-lift long-range FPV drone as the core operational platform. Leveraging its 10-inch high-strength heavy-lift airframe, 6kg maximum / 4kg standard operating payload, 45-minute extended no-load endurance, 10km long-range control link, 1.2G/5.8G dual-band VTX, and 165° night-vision wide-angle imaging, it provides high-payload, stable long-range, multi-scenario and cost-effective unmanned operation solutions for four core industrial scenarios: industrial facility inspection & security, emergency rescue aerial reconnaissance, aerial mapping & regional exploration, and light-load logistics point delivery. It addresses core industry pain points such as insufficient payload and endurance of small and medium drones, unstable long-range signals, high cost of professional industrial UAVs, and poor day-night operation adaptability, achieving the optimal balance of efficiency, cost and adaptability for medium-range medium-load industrial operation scenarios.
Four Common Pain Points in Industrial Operations
- Insufficient payload and endurance of small and medium drones: FPV drones of 8 inches and below generally have a payload under 3.5kg with short flight time, unable to carry professional equipment for medium-long range inspection and survey missions, with limited operating radius and duration.
- Unstable long-range signal with poor penetration in complex environments: Common drones have short video and control range, with signal dropout in mountain and built-up obstructed environments, resulting in unreliable long-distance operations.
- Excessive cost of professional industrial UAVs: Large industrial-grade UAVs have high procurement and maintenance costs, delivering very poor value for medium-scale operation tasks, with large form factors, slow deployment and poor flexibility.
- Poor day-night operation adaptability: Common drones deliver poor image quality at night and in low-light environments, with limited night operation capability, making 24/7 continuous operation difficult.
Four Custom Scenario Solutions
Scenario 1: Industrial Facility Inspection & Security Patrol
Applicable scenarios: Power line inspection, oil & gas pipeline corridor patrol, factory security patrol, petrochemical facility inspection, infrastructure special inspection
Pain Points
- Power, pipeline and factory facilities cover wide areas. Manual inspection involves high labor intensity, high altitude risk and long cycles, with delayed detection of defects and anomalies.
- Small and medium drones have insufficient payload to carry professional inspection equipment, with insufficient inspection accuracy and professionalism. Short-range links fail to fully cover long corridor operations.
- Professional inspection UAVs are expensive with complex deployment processes, delivering poor value for routine inspection at medium-sized stations.
Solution Configuration
| Category | Configuration | Description |
|---|---|---|
| Operation Drone | Lion 10 10-inch heavy-lift FPV drone (Inspection edition) | 10-inch heavy-lift airframe, 4kg standard payload, 915MHz long-range receiver, 5.8G HD VTX, 165° night-vision wide-angle |
| Ground Terminal | Industrial ground receiving station, inspection data analysis terminal | Real-time video return, defect identification, data recording and analysis |
| Power Supply | High-capacity LiPo ×5 + balance charger | 45-minute no-load endurance; multiple packs for all-day inspection operations |
| Auxiliary Equipment | Portable carrying case, spare propellers, calibration tools | Convenient field transition; spares and calibration ensure operational accuracy |
Operation Process
- Inspection planning: Plan inspection routes, key detection points and flight parameters based on line and station distribution.
- Cruise inspection: Drone flies autonomously along planned routes, collecting visible and thermal data simultaneously and transmitting back in real time.
- Defect marking: Automatically mark locations and data when appearance damage or temperature anomalies are found, and record them for archiving.
- Report generation: Export data after inspection to generate professional inspection reports, sorting out defect levels and rectification suggestions.
Solution Value
- 4kg standard payload carries medium inspection equipment, completing both visual and temperature detection in one flight, improving inspection efficiency by 5–7 times compared with manual.
- 10km long-range control link covers long corridors in a single sortie, eliminating frequent transitions and greatly improving inspection efficiency.
- Procurement cost is much lower than professional industrial inspection drones, delivering excellent value for routine inspection at medium-sized stations.
Scenario 2: Emergency Rescue & Aerial Reconnaissance
Applicable scenarios: Fire scene aerial reconnaissance, mountain & water search and rescue, disaster site assessment, emergency supply delivery
Pain Points
- Disaster and accident sites are complex and dangerous, making it difficult for personnel to quickly penetrate. On-site conditions are unclear, leaving command decisions without evidence.
- Small and medium drones have insufficient payload and poor signal, prone to disconnection in complex environments, struggling to support long-duration reconnaissance and material delivery.
- Large emergency UAVs deploy slowly and are expensive, difficult for grassroots teams to equip with slow response.
Solution Configuration
| Category | Configuration | Description |
|---|---|---|
| Operation Drone | Lion 10 10-inch heavy-lift FPV drone (Reconnaissance edition) | 10-inch heavy-lift airframe, 6kg max payload, 915MHz long-range receiver, 1.2G diffraction VTX, night-vision wide-angle |
| Command Terminal | Portable command terminal, HD display | Frontline command views live dual-sensor footage in real time to coordinate rescue forces |
| Power Supply | High-capacity LiPo ×4 + fast charger | Quick battery swaps for continuous reconnaissance operations |
| Auxiliary Equipment | Portable protective case, spare wear parts, lighting module | Rapid deployment, night operation assistance |
Operation Process
- Rapid deployment: Quickly unfold the drone on arrival and launch to rapidly reach the target area.
- On-site reconnaissance: Capture visible and thermal footage from the air, transmit back to command in real time, and quickly locate trapped people, fire sources and hazards.
- Target delivery: Carry emergency supplies as required and deliver precisely to the target area.
- Continuous support: Rotate batteries for sustained operations, monitoring on-site situation changes to support ground rescue efforts.
Solution Value
- 10-inch airframe for rapid deployment, operational immediately on arrival with much faster emergency response than large UAVs.
- 10km long-range link + 1.2G diffraction band delivers stable signal in complex obstructed and smoke environments with long reconnaissance range and clear footage.
- 6kg maximum payload carries small rescue equipment and supplies, combining both reconnaissance and delivery in one platform.
- Night-vision imaging supports night operations with strong all-weather emergency response capability.
Scenario 3: Aerial Mapping & Regional Exploration
Applicable scenarios: Topographic mapping, engineering survey, outdoor exploration, regional resource investigation
Pain Points
- Small and medium drones have insufficient payload to carry professional survey equipment, failing to meet engineering accuracy standards.
- Short operating range and small coverage require multiple takeoffs for large-area operations, with low efficiency and large stitching errors.
- Professional surveying UAVs are expensive and process-heavy, delivering poor value for medium-scale survey tasks.
Solution Configuration
| Category | Configuration | Description |
|---|---|---|
| Operation Drone | Lion 10 10-inch heavy-lift FPV drone (Survey edition) | 10-inch heavy-lift airframe, 6kg max payload, 915MHz long-range receiver, HD VTX, long-endurance tuning |
| Survey Payload | Small survey camera, high-precision positioning module | Compatible with light survey equipment mounting, meeting professional survey accuracy requirements |
| Data Terminal | Ground data processing terminal, mapping processing software | Real-time image data return, pre-processing and mapping processing |
| Power Supply | High-capacity LiPo ×5 + balance charger | Ensures long-duration continuous aerial survey operations |
Operation Process
- Survey area planning: Plan flight routes, overlap, altitude and camera parameters according to survey scope and accuracy requirements.
- Aerial acquisition: Drone flies along planned routes, collecting images and positioning data simultaneously.
- Quality check: Check data integrity and overlap after each sortie, re-shooting missing and substandard areas.
- Office processing: Import data for stitching and correction to generate orthophotos, topographic maps and other survey deliverables.
Solution Value
- 6kg maximum payload carries professional small survey equipment and positioning modules, with mapping accuracy meeting specifications for medium-scale engineering and exploration projects.
- 45-minute extended endurance and 10km operating radius cover large areas in a single sortie, improving efficiency several times over manual surveying.
- Procurement and maintenance costs are much lower than professional survey UAVs, delivering outstanding cost performance for medium-scale survey tasks.
Scenario 4: Light-Load Logistics & Point Delivery
Applicable scenarios: Small material transportation, remote point delivery, work equipment transfer, emergency supply drop
Pain Points
- Mountain and remote areas with no road access result in low efficiency and high cost for material and equipment transfer.
- Small and medium drones have limited payload with insufficient medium-distance delivery capability. Large logistics UAVs are expensive, delivering poor value for small tasks.
- Poor signal in complex environments results in insufficient delivery accuracy and reliability.
Solution Configuration
| Category | Configuration | Description |
|---|---|---|
| Operation Drone | Lion 10 10-inch heavy-lift FPV drone (Logistics edition) | 10-inch heavy-lift airframe, 6kg max payload, 915MHz long-range receiver, long-endurance tuning |
| Mount System | Precision delivery mechanism / cargo sling | Compatible with small and medium materials and equipment for loading and release |
| Dispatch Terminal | Dispatch command terminal, real-time monitor | Material scheduling, route planning, delivery control |
| Power Supply | High-capacity LiPo ×6 + fast charger | Multiple packs for continuous transfer operations |
Operation Process
- Demand submission: Submit transfer / delivery requests, specifying material weight, origin/destination and timeline.
- Dispatch planning: Plan optimal routes, assign flight tasks and avoid obstacles and signal dead zones.
- Precision delivery: Drone flies autonomously after loading, releasing supplies precisely at the target area.
- Record management: Log operational data to generate transfer logs and cost accounting.
Solution Value
- 6kg maximum payload covers the transfer needs of small and medium tools, supplies and equipment, adapting to most light-load logistics scenarios.
- 10km long-range link ensures medium-distance delivery control, with strong 915MHz signal penetration for stable delivery in complex environments.
- Procurement and maintenance costs are much lower than large logistics UAVs, delivering excellent value for small and medium light-load tasks.
5-Step Solution Implementation Process
- Demand research and solution customization: Investigate operation scenarios, core demands and environmental conditions, and customize corresponding payloads, configurations and operation processes.
- Equipment deployment and training: Deliver and commission equipment, conduct operation training, safety training and scenario-based practical training.
- Trial operation and parameter optimization: Conduct on-site trial operation, and adjust FC parameters, VTX power and route logic based on actual performance.
- Formal operation and process standardization: Launch formal operations, and standardize operating procedures, management specifications and emergency plans.
- Operation & maintenance support and iterative optimization: Provide regular maintenance and spare parts support, and iteratively optimize solution configurations according to business development.
Core Solution Values
✅ Outstanding payload capacity: 6kg max / 4kg standard payload covers most medium-load industrial operational needs, balancing payload and maneuverability.
✅ Excellent long-range performance: 10km control range with dual-band options, strong anti-interference in complex environments for stable medium-long-range operations.
✅ Long-endurance high efficiency: 45-minute no-load endurance with large single-flight coverage and high operational efficiency.
✅ Wide scenario coverage: Covers four industrial scenarios: inspection, reconnaissance, surveying and logistics, all in one drone with strong expandability.
✅ Significant cost advantage: Procurement and maintenance costs are much lower than large industrial UAVs, delivering optimal return on investment for medium-scale operations.
✅ All-weather operation capability: 165° night-vision wide-angle imaging delivers clear imaging in low-light night environments, with strong day-night adaptability.
Tiered Configuration Procurement Advice
- Entry long-range edition: Standard drone + ground receiving terminal + 3 batteries, suitable for medium-long range flight practice and basic operation training.
- Inspection operation edition: Standard drone + industrial receiving terminal + 5 batteries, suitable for power and factory inspection and security patrol.
- Survey exploration edition: Standard drone + survey payload + data processing terminal + 5 batteries, suitable for aerial mapping and regional exploration operations.
- Team operation edition: Multiple drones + command & dispatch system + bulk spares + charging support, suitable for organizational scaled operations.
