In Stock — Ready to Ship
17-inch FPV drone
★ Pilot RewardsEarn Pilot Points with this purchase
Fast, Tracked ShippingOrders ship from our U.S. warehouse with tracking. Delivery estimates appear during checkout.
Product Overview:
This 17-inch FPV drone is a heavy-duty professional model with a large wheelbase frame. It supports a standard payload of 10kg and a maximum payload of 13kg. Powered by an 8S-10S high-spec powertrain, equipped with a starlight-level color night vision camera and multi-band high-power VTX, it features ultra-long endurance and strong load capacity, suitable for industrial scenarios such as heavy-load transportation, large-scale mapping and long-distance special operations.
Frame
- Wheelbase: 745mm
- Frame size: 510 × 525 × 70mm
- Weight: ≈3.5kg (exclude battery)
- Standard loading: 10kg; Max loading: 13kg
Flight Control
- Flight controller model: F405 V3
- Gyroscope: ICM42688P
- Mounting hole position: 30.5 × 30.5mm
ESC (Electronic Speed Controller)
- ESC model: 120A AM32
- Input voltage: 8S-10S, 33.6V-42V
- Continuous current: 120A
- Peak current: 130A (10 seconds)
Camera
- Sensor type: Starlight 1/2.7″ CMOS Color Night Vision Sensor
- Minimum illumination: 0.001Lux
VTX (Video Transmitter)
- Frequency & power (optional): 3.3G: 4W; 4.9G: 1.6W / 2.5W / 4W; 5.8G: 1.6W / 2.5W / 4W; 6.5G: 2W
- Configuration note: Either-or option among the above frequency solutions
Powertrain (Motor & Propeller)
- Motor model: 5322 Brushless Motor
- KV value: 330KV (Customizable)
- Input voltage: 33.6V (8S)
- Propeller: 3-blade 1708 propeller
Accessories
- Antenna: 5.8G long-range high-gain RHCP antenna
- Battery strap: 20×400mm battery strap
- Receiver: ELRS 915M / 2.4G Receiver (either-or)
Flight Performance
- Flight time: 25mins (with 8.0kg loading, 8S 22000mAh Battery)
| SKU | IUAV-14179 |
|---|
